Like nothing on the market today, the LM5200 for linear or gantry milling can be configured in almost any position! Modular bed sections allow the length to be expanded from 48 to 96 inches (1219.2 to 2438.4 mm) without losing rigidity (with 36 to 84 inches [914.4 to 2133.6 mm] of travel). This portable mill offers maximum flexibility for operators that have diverse milling needs. Solid bed options are available.
Max. X-Axis Travel:
84 inches (2133.6 mm)
Max. Y-Axis Travel:
34 inches (863.6 mm)
Max. Vertical Travel:
4 inches (101.6 mm)
Spindle Size:
4 – 6 inches (101.6 – 145.4 mm)
Power Option:
Hydraulic
The CLIMAX LM5200 Milling Machine revolutionizes both the capabilities and functionality of portable mills. Four main features make this one of the best milling machines on the market today:
Rigid, Modular Design
Unique modular bed design allows shorter bed sections to be combined to fit the length of the work area without losing rigidity.
Unique bed length section design provides superior rigidity across the entire bed length.
Connection plates and fasteners optimized to provide the ultimate in rigidity, even when bed is extended by 2 or 3 times the original length.
Flexible Configuration & Operation
The innovative new design of these CLIMAX Milling Machines allow them to be configured for traditional linear milling, or simply split the rails lengthwise to configure for gantry milling!
Electric feeds can be mounted on the X, Y or Z axis.
Machining capabilities include milling, drilling and even boring.
Powerful, Precise Machining
Features heavy duty spindle design and a choice of Hydraulic Power Units – a 10 Hp (7.5 kW) HPU allows use of cutter heads of up to 6 inches (152.4 mm) in diameter.
Milling can be done in any axis, with a milling head that can rotate 360° with an optional swivel plate for optimal spindle flexibility.
Fast, aggressive milling in horizontal, vertical, or inverted applications.
Provides reliable, precise milling to meet tight machining tolerances in both linear and gantry mill configurations.
Reduced Friction Rail Technology
Reduced friction rail system allows extremely smooth, continuous, and non stick-slip travel.
Precisely machined and aligned rails with advanced lubrication make machining applications smooth and efficient.
Low friction system reduces maintenance costs and extends product life.
Precision ball screws in X, Y and Z- axis assemblies allow precise location of milling head.
